Lab 9: Regression¶
Welcome to Lab 9!
Today we will get some hands-on practice with linear regression.
Helpful Resources:¶
Recommended Readings:
Getting help on lab: Whenever you feel stuck or need some further clarification, find a GSI or tutor, and they’ll be happy to help!
As a reminder, here are the policies for getting full credit if you are in regular lab (Lab is worth 20% of your final grade):
80% of lab credit will be attendance-based. To receive attendance credit for lab, you must attend the full discussion portion (first hour) at which point the GSI will take attendance.
The remaining 20% of credit will be awarded for submitting the programming-based assignment to Pensive by the deadline (5pm on Friday) with all test cases passing.
If you are in self-service lab, 100% of credit will be awarded for submitting the programming-based assignment to Pensive by the deadline (5pm on Friday) with all test cases passing.
Submission: Once you’re finished, run all cells besides the last one, select File > Save Notebook, and then execute the final cell. The result will contain a zip file that you can use to submit on Pensive.
Let’s begin by setting up the tests and imports by running the cell below.
# Run this cell, but please don't change it.
# These lines import the Numpy and Datascience modules.
import numpy as np
from datascience import *
# These lines do some fancy plotting magic.
import matplotlib
%matplotlib inline
import matplotlib.pyplot as plots
plots.style.use('fivethirtyeight')
import warnings
warnings.simplefilter('ignore', FutureWarning)1. How Faithful is Old Faithful?¶
Old Faithful is a geyser in Yellowstone National Park that is famous for eruption on a fairly regular schedule. Run the cell below to see Old Faithful in action!
# For the curious: this is how to display a YouTube video in a
# Jupyter notebook. The argument to YouTubeVideo is the part
# of the URL (called a "query parameter") that identifies the
# video. For example, the full URL for this video is:
# https://www.youtube.com/watch?v=wE8NDuzt8eg
from IPython.display import YouTubeVideo
YouTubeVideo("wE8NDuzt8eg")Some of Old Faithful’s eruptions last longer than others. Whenever there is a long eruption, it is usually followed by an even longer wait before the next eruption. If you visit Yellowstone, you might want to predict when the next eruption will happen, so that you can see the rest of the park instead of waiting by the geyser.
Today, we will use a dataset on eruption durations and waiting times to see if we can make such predictions accurately with linear regression.
The dataset has one row for each observed eruption. It includes the following columns:
duration: Eruption duration, in minuteswait: Time between this eruption and the next, also in minutes
Run the next cell to load the dataset.
faithful = Table.read_table("faithful.csv")
faithfulQuestion 1.0. The following statements are the unordered steps of linear regression.
Compute the parameters of the regression line: the slope and the intercept.
Evaluate the regression line by computing the line’s RMSE and analyzing the residuals plot.
Use the regression line to generate predictions for each x value.
Determine if linear regression is a reasonable method by visualizing your data and computing the correlation coefficient.
Make an array called least_squares_order that contains the correct order of a linear regression analysis, where the first item of the array is the first step of a linear regression analysis and the last item of the array is the last step of a linear regression analysis.
least_squares_order = ...grader.check("q1_0")We would like to use linear regression to make predictions, but that won’t work well if the data aren’t roughly linearly related. To check that, we should look at the data.
Question 1.1. Make a scatter plot of the data. It’s conventional to put the column we want to predict on the vertical axis and the other column on the horizontal axis.
...Question 1.2. Are eruption duration and waiting time roughly linearly related based on the scatter plot above? Is this relationship positive?
Type your answer here, replacing this text.
We’re going to continue with the assumption that they are linearly related, so it’s reasonable to use linear regression to analyze this data.
We’d next like to plot the data in standard units. If you don’t remember the definition of standard units, textbook section 14.2 might help!
Question 1.3. Compute the mean and standard deviation of the eruption durations and waiting times. Then create a table called faithful_standard containing the eruption durations and waiting times in standard units. The columns should be named duration (standard units) and wait (standard units).
duration_mean = ...
duration_std = ...
wait_mean = ...
wait_std = ...
faithful_standard = Table().with_columns(
"duration (standard units)", ...,
"wait (standard units)", ...)
faithful_standardgrader.check("q1_3")Question 1.4. Plot the data again, but this time in standard units.
...You’ll notice that this plot looks the same as the last one! However, the data and axes are scaled differently. So it’s important to read the ticks on the axes.
Question 1.5. Among the following numbers, which would you guess is closest to the correlation between eruption duration and waiting time in this dataset? (Hint: Think about which values correlation can take on)
-2
-1
0
1
2
Assign correlation to the number corresponding to your guess (either 1, 2 3, 4, or 5).
correlation = ...grader.check("q1_5")Question 1.6. Compute the correlation coefficient: r.
Hint: Use faithful_standard. Section 15.1 explains how to do this.
r = ...
rgrader.check("q1_6")2. The regression line¶
Recall that the correlation is the slope of the regression line when the data are put in standard units.
The next cell plots the regression line in standard units:
Then, it plots the data in standard units again, for comparison.
def plot_data_and_line(dataset, x, y, point_0, point_1):
"""Makes a scatter plot of the dataset, along with a line passing through two points."""
dataset.scatter(x, y, label="data")
xs, ys = zip(point_0, point_1)
plots.plot(xs, ys, label="regression line")
plots.legend(bbox_to_anchor=(1.5,.8))
plot_data_and_line(faithful_standard,
"duration (standard units)",
"wait (standard units)",
[-2, -2*r],
[2, 2*r])How would you take a point in standard units and convert it back to original units? We’d have to “stretch” its horizontal position by duration_std and its vertical position by wait_std. That means the same thing would happen to the slope of the line.
Stretching a line horizontally makes it less steep, so we divide the slope by the horizontal stretching factor. Stretching a line vertically makes it more steep, so we multiply the slope by the vertical stretching factor.
Question 2.1. Calculate the slope of the regression line in original units, and assign it to slope.
(If the “stretching” explanation is unintuitive, consult section 15.2 in the textbook.)
slope = ...
slopegrader.check("q2_1")We know that the regression line passes through the point (duration_mean, wait_mean). Recall that the general equation of the regression line in original units is:
For this scenario, that would become:
Question 2.2. Calculate the intercept in original units and assign it to intercept. Section 15.2.5 may be helpful.
intercept = ...
interceptgrader.check("q2_2")3. Investigating the regression line¶
The slope and intercept tell you exactly what the regression line looks like. To predict the waiting time for an eruption, multiply the eruption’s duration by slope and then add intercept.
Question 3.1. Compute the predicted waiting time for an eruption that lasts 2 minutes, and for an eruption that lasts 5 minutes.
two_minute_predicted_waiting_time = ...
five_minute_predicted_waiting_time = ...
# Here is a helper function to print out your predictions.
# Don't modify the code below.
def print_prediction(duration, predicted_waiting_time):
print("After an eruption lasting", duration,
"minutes, we predict you'll wait", predicted_waiting_time,
"minutes until the next eruption.")
print_prediction(2, two_minute_predicted_waiting_time)
print_prediction(5, five_minute_predicted_waiting_time)grader.check("q3_1")The next cell plots the line that goes between those two points, which is (a segment of) the regression line.
plot_data_and_line(faithful, "duration", "wait",
[2, two_minute_predicted_waiting_time],
[5, five_minute_predicted_waiting_time])Question 3.2. Make predictions for the waiting time after each eruption in the faithful table. (Of course, we know exactly what the waiting times were! We are doing this so we can see how accurate our predictions are.) Put these numbers into a column in a new table called faithful_predictions. Its first row should look like this:
| duration | wait | predicted wait |
|---|---|---|
| 3.6 | 79 | 72.1011 |
Hint: Your answer can be just one line, though you are not limited to one line. There is no need for a for loop; use array arithmetic instead.
faithful_predictions = ...
faithful_predictionsgrader.check("q3_2")Question 3.3. How close were we? Compute the residual for each eruption in the dataset. The residual is the actual waiting time minus the predicted waiting time. Add the residuals to faithful_predictions as a new column called residual and name the resulting table faithful_residuals.
As mentioned in Chapter 15.6, a useful property of linear regression is that the sum of the residuals will always be zero. You can always check this to make sure you’ve calculated your residuals correctly. Note it may be slightly off from zero due to rounding errors.
Feel free to copy and paste this line of code, to check your work! Note that the answer may be very slightly different from zero due to rounding errors in python.
sum(faithful_residuals.column('residual'))Hint: Again, your code will be much simpler if you don’t use a for loop.
Hint: residual = actual_value − predicted_value
residuals = ...
faithful_residuals = ...
faithful_residualsgrader.check("q3_3")Here is a plot of the residuals you computed. Each point corresponds to one eruption. It shows how much our prediction over- or under-estimated the waiting time.
faithful_residuals.scatter("duration", "residual", color="r")There isn’t really a pattern in the residuals, which confirms that it was reasonable to try linear regression. It’s true that there are two separate clouds; the eruption durations seemed to fall into two distinct clusters. But that’s just a pattern in the eruption durations, not a pattern in the relationship between eruption durations and waiting times.
4. How accurate are different predictions?¶
Earlier, you should have found that the correlation is fairly close to 1, so the line fits fairly well on the training data. That means the residuals are overall small (close to 0) in comparison to the waiting times.
We can see that visually by plotting the waiting times and residuals together:
# Just run this cell.
faithful_residuals.scatter("duration", "wait", label="actual waiting time", color="blue")
plots.scatter(faithful_residuals.column("duration"), faithful_residuals.column("residual"), label="residual", color="r")
plots.plot([2, 5], [two_minute_predicted_waiting_time, five_minute_predicted_waiting_time], label="regression line")
plots.legend(bbox_to_anchor=(1.7,.8));However, unless you have a strong reason to believe that the linear regression model is true, you should be wary of applying your prediction model to data that are very different from the training data.
Question 4.1. In faithful, no eruption lasted exactly 0, 2.5, or 60 minutes. Using this line, what is the predicted waiting time for an eruption that lasts 0 minutes? 2.5 minutes? An hour?
zero_minute_predicted_waiting_time = ...
two_point_five_minute_predicted_waiting_time = ...
hour_predicted_waiting_time = ...
print_prediction(0, zero_minute_predicted_waiting_time)
print_prediction(2.5, two_point_five_minute_predicted_waiting_time)
print_prediction(60, hour_predicted_waiting_time)grader.check("q4_1")Question 4.2. For each prediction, state whether you think it’s reliable and explain your reasoning.
Type your answer here, replacing this text.
The scatter plot below shows the relationship between eruption durations on the x-axis and the wait time to the next eruption on the y-axis.
It appears from the scatter diagram that there are two clusters of points: one for durations around 2 and another for durations between 3.5 and 5. A vertical line at 3 divides these two clusters.
faithful.scatter("duration", "wait", label="actual waiting time", color="blue")
plots.plot([3, 3], [40, 100]);The standardize function from lecture appears below, which takes in a table with numerical columns and returns the same table with each column converted into standard units.
# Just run this cell.
def standard_units(any_numbers):
"Convert any array of numbers to standard units."
return (any_numbers - np.mean(any_numbers)) / np.std(any_numbers)
def standardize(table):
"""Return a table in which all columns of t are converted to standard units."""
t_su = Table()
for label in table.labels:
t_su = t_su.with_column(label + ' (su)', standard_units(table.column(label)))
return t_suQuestion 5.1. Separately compute the correlation coefficient r for all the points with a duration below 3 and then for all the points with a duration above 3. To do so, create a function that computes r from a table, and then pass in two different tables of points, called below_3 and above_3.
Hint: You can assume that the table does not have any duration values that are exactly 3.
def corr_coeff(table):
"""Return the regression coefficient for columns 0 & 1."""
t_su = standardize(table)
...
below_3 = ...
above_3 = ...
below_3_r = corr_coeff(below_3)
above_3_r = corr_coeff(above_3)
print("For points below 3, r is", below_3_r, "; for points above 3, r is", above_3_r)grader.check("q5_1")Question 5.2. Complete the functions slope_of and intercept_of below.
When you’re done, the functions wait_below_3 and wait_above_3 should each use a different regression line to predict a wait time for a duration. The first function should use the regression line for all points with duration below 3. The second function should use the regression line for all points with duration above 3.
def slope_of(table, r):
"""Return the slope of the regression line for table in original units.
Assume that column 0 contains x values and column 1 contains y values.
r is the regression coefficient for x and y.
"""
...
def intercept_of(table, r):
"""Return the intercept of the regression line for table in original units.
Assume that column 0 contains x values and column 1 contains y values.
r is the regression coefficient for x and y.
"""
slope = slope_of(table, r)
...
below_3_slope = slope_of(below_3, below_3_r)
below_3_intercept = intercept_of(below_3, below_3_r)
above_3_slope = slope_of(above_3, above_3_r)
above_3_intercept = intercept_of(above_3, above_3_r)
def wait_below_3(duration):
return below_3_slope * duration + below_3_intercept
def wait_above_3(duration):
return above_3_slope * duration + above_3_interceptgrader.check("q5_2")The plot below shows the two different regression lines, one for each cluster, along with the original regression line!
faithful.scatter(0, 1)
plots.plot([2, 5], [two_minute_predicted_waiting_time, five_minute_predicted_waiting_time])
plots.plot([1, 3], [wait_below_3(1), wait_below_3(3)])
plots.plot([3, 6], [wait_above_3(3), wait_above_3(6)]);Question 5.3. Write a function predict_wait that takes a duration and returns the predicted wait time using the appropriate regression line, depending on whether the duration is below 3 or greater than 3.
Hint: Consider using conditional statements.
def predict_wait(duration):
...grader.check("q5_3")The predicted wait times for each point appear below.
faithful_pred_split = faithful.with_column('predicted', faithful.apply(predict_wait, 'duration'))
faithful_pred_split.scatter(0)Question 5.4. Do you think the predictions produced by predict_wait would be more or less accurate than the predictions from the regression line you created in section 2? How could you tell?
Type your answer here, replacing this text.
The following cell will plot the residuals for each eruption in the dataset when we have one regression line and two regression lines. We also see the average magnitude of the residual values.
# Just run this cell
faithful_pred_split_residuals = faithful_pred_split.with_column('residual', faithful_pred_split.column(1) - faithful_pred_split.column(2))
plots.scatter(faithful_residuals.column('duration'), faithful_residuals.column('residual'), label='one regression line')
plots.scatter(faithful_pred_split_residuals.column('duration'), faithful_pred_split_residuals.column('residual'), label='two regression lines');
plots.axis([1, 6, -15, 15])
plots.legend(bbox_to_anchor=(1.5,.8));
print("Average Magnitude of Residual Values for One Regression Line: ", np.mean(abs(faithful_residuals.column('residual'))))
print("Average Magnitude of Residual Values for Two Regression Lines: ", np.mean(abs(faithful_pred_split_residuals.column('residual'))))The residual plot for the wait times when they are predicted by two regression lines (red) doesn’t really have a pattern, which confirms that it was also appropriate to use linear regression in our “Divide and Conquer” scenario. How do the two residual plots compare?
6. Jupytutor Survey¶
We hope your experience using Jupytutor has been smooth and helpful for you!
Please fill out the survey below and input the secret phrase that is shown at the end of the form when you submit. Please assign this phrase to secret as a string in the cell below!
Find the survey here.
secret = ...grader.check("q6")
You’re done with lab!
Important submission information:
Run all the tests and verify that they all pass
Save from the File menu
Run the final cell to generate the zip file
Click the link to download the zip file
Then, go to Pensive and submit the zip file to the corresponding assignment. The name of this assignment is “Lab XX Autograder”, where XX is the lab number -- 01, 02, 03, etc.
If you finish early in Regular Lab, ask one of the staff members to check you off.
It is your responsibility to make sure your work is saved before running the last cell.
To double-check your work, the cell below will rerun all of the autograder tests.
grader.check_all()Submission¶
Make sure you have run all cells in your notebook in order before running the cell below, so that all images/graphs appear in the output. The cell below will generate a zip file for you to submit. Please save before exporting!
# Save your notebook first, then run this cell to export your submission.
grader.export(pdf=False)
